Pentek 1/2″ #10 Slim-Line Filter Housing – 10″ Black/Blue, No Pressure Relief (12-Pack) (Model #158196)

Description

**Please call us before placing an order to check the availability of products to avoid unwanted delays/cancellations.

FEATURES & BENEFITS

• Slim design reduces space required for installation without sacrificing capacity
• Available in 5″, 10″ and 20″ lengths
• Optional pressure relief/bleed button on inlet side of cap
• Leak-proof seal
• Available with clear or opaque sumps

 SPECIFICATION

• Part Number: 158196
• Ports: 1/2″NPT
• Maximum Dimensions: 11.75″ x 4.38″ (298 mm x 111 mm)
• Housing: Polypropylene (opaque) or Styrene Acrylonitrile (clear)
• Cap: Reinforced polypropylene
• Button Assembly: 300 Series stainless steel, EPDM, and polypropylene
• O-Ring: Buna-N
• Temperature Rating: 40-125°F (4.4-51.7ºC)
• Maximum Pressure: 125 psi (8.6 bar)
