Pentek Pbh-420-1 Bag Filter Vessel Assembly, 20-Inch Length, 1-Inch Npt, 4-Pack – Model 150367

Description

**Please call us before placing an order to check the availability of products to avoid unwanted delays/cancellations.

Pentek 20″ Bag Filter Housing Kit – 1″ FNPT Connections

Pentair/Pentek Standard Bag Vessel Assemblies keep your system on stream longer by reducing bag filter change time. They are made of lightweight corrosion resistant polypropylene to give you all the strength you need without the weight.

Install as a duplex system for totally uninterrupted flow rates. All PBH Series Vessels come complete with gauge, wrench and 3/8″ drain valve. The single large ACME thread closure ensures quick opening and positive sealing.

Filter bags are available in polypropylene felt, absolute-rated high efficiency polypropylene and nylon monofilament mesh—ideal for filtering and straining applications from 1-800 microns.

Molded from rugged reinforced polypropylene, Bag Vessel Filter Housings offer outstanding chemical compatibility and are ideal for use in a variety of low-flow applications. These applications include residential prefiltration, food service, along with commercial and industrial applications for water filtration and chemical filtration. They are equipped with a black reinforced polypropylene cap.

What’s in the Kit?

Cap
Sump
Pressure Gauge
Bag Holder
Ball Valve Drain
Gaskets, seal and O-ring
Wrench

Specifications

Model – PBH-420-1
Connections – 1″FNPT in/out
Size – 22.38″ x 7.25″ (594 x 184 mm)
Housing & Cap – Polypropylene
Gauge: Brass (lead-free)
Drain & Vent Plug:  Polypropylene
Ball Valve: PVC
Basket: Polypropylene
O-ring & Gaskets: Buna-N & Santoprene
Maximum Operating Temperature: 100F (37.8C)-165°F (4.4-74°C)
Part – 150367
